MS7220 Mastech
Description
MS7220 Mastech
- Maximum voltage applied between any terminal and earth ground or between any two terminals: 30V
- Storage temperature: -40℃ to 60℃
- Operating temperature: -10℃ to 55℃
- Operating altitude: 3000 meters maximum
- Temperature coefficient: 0.05 x specified accuracy per ℃ for temperature range -10℃ to 18℃ and 28℃ to 55℃
- Relative humidity: 95% up to 30℃, 75% up to 40℃, 45%up to 50℃, 35% up to 55℃
- Vibration: Random 2 g, 5 Hz to 500 Hz
- Shock:1 meter drop test
- Power requirement: Single 9V battery (ANSI / NEDA 1604A or IEC 6LR61)
- Size: 190mm(L) x 89mm(W) x 42mm(H)
- Weight: 350g (include battery)
- Safe rating: RoHS
| Thermocouple Satandard Scale |
| Thermocouple Type | Satandard | Scale | |
| J, K, T, E, R, S, B, N | NIST 175 | ITS-90 | |
|
|||||||
| J | -200℃~1200℃ / -328℉~2192℉ | 0.1 ℃ or ℉ | |
| K | -200℃~1370℃ / -328℉~2498℉ | 0.1 ℃ or ℉ | |
| T | -200℃~400℃ / -328℉~752℉ | 0.1 ℃ or ℉ | |
| E | -200℃~950℃ / -328℉~1742℉ | 0.1 ℃ or ℉ | |
| R | -20℃~1750℃ / -4℉~3182℉ | 1 ℃ or ℉ | |
| S | -20℃~1750℃ / -4℉~3182℉ | 1 ℃ or ℉ | |
| B | 600℃~1800℃ / 1112℉~3272℉ | 1 ℃ or ℉ | |
| N | -250℃~1300℃ / -418℉~2372℉ | 0.1 ℃ or ℉ | |
| Millivolt Range and Resolution |
| Mode | Range | Resolution | |
| mV | -10mV~75mV | 0.01mV | |
| Millivolt Measure and Soure (MAX input voltage:30V) |
| Range | Resolution | Accuracy | |
| -10mV~75mV | 0.01mV | +-(0.02%+2) | |
| Temperature Measure and Simulate (MAX input voltage:30V) |
| Type | Resolution | Error | Accuracy |
| J, K, T, E,N | 0.1 ℃ or ℉ | +-(0.3%℃+10uV) | +-0.2℃ |
| R, S, B | 1 ℃ or ℉ | +-(0.3%℃+10uV) | +-0.2℃ |
For More Specification Click On below:
http://www.p-mastech.com/product/detail/408
