APM2.8 ArduPilot Mega 2.8

Introduction:

This is the new APM 2.8 autopilot module. The sensors are exactly the same

as with APM2.6, however this version does not have an onboard compass,

which makes this version ideal for use with multicopters and rovers.

The APM 2.8 is a complete open source autopilot system and the bestselling

technology that won the prestigious 2012 Outback Challenge UAV competition.

It allows the user to turn any fixed, rotary wing or multirotor vehicle

(even cars and boats) into a fully autonomous vehicle; capable of performing

programmed GPS missions with waypoints. Available with top or side

Features:

- Arduino Compatible!


- Can be ordered with top entry pins for attaching connectors vertically, or as

  side entry pins to slide your connectors in to either end horizontally


- Includes 3-axis gyro, accelerometer and magnetometer, along with a high-

  performance barometer


- Onboard 4 MegaByte Dataflash chip for automatic datalogging


- Optional off-board GPS, uBlox LEA-6H module with Compass.


- One of the first open source autopilot systems to use Invensense's 6 DoF


  Accelerometer/Gyro MPU-6000.


- Barometric pressure sensor upgraded to MS5611-01BA03, from Measurement

  Specialties.


- Atmel's ATMEGA2560 and ATMEGA32U-2 chips for processing and usb functions  respectively.
