XB-866
Specifications
XB-866 Digital Multimeter
1.A Professional multimeter
2.Easy to use, cheap
3.Simple and Practical
4.With Diode test
Parameter
1.The meter is small and has the cover attached to it.
2.It is easy to carry with you in a pocket.
3.The switch works good and the meter is reasonably accurate.
4.It uses AAA batteries, much better than a 9 volt battery because those are always too weak.
|
Basic Function |
Range |
Basic accuracy |
|
DC Voltage |
0.1mV - 1000V |
±(0.5%+4) |
|
AC Voltage |
0.1mV - 1000V |
±(0.8%+6) |
|
Resistance |
0.1Ω - 40MΩ |
±(0.8%+4) |
|
Capacitance |
0.1μA - 10A |
±(3.5%+8) |
|
Frequency |
100Hz/1kHz/10kHz/100kHz/1MHz/10MHz |
±(0.5%+4) |
|
Special Function |
||
|
Diode test |
√ |
|
|
Continuity buzzer |
√ |
|
|
Low battery indication |
√ |
|
|
|
|
|
|
Auto power off |
√ |
|
|
Function protection |
√ |
|
|
Frequency |
√ |
|
|
Duty cycle measuring |
√ |
|
|
Input impedance |
10MΩ |
|
|
Sampling rate |
3 times/s |
|
|
AC Frequency response |
40~400Hz |
|
|
Operation way |
Auto range |
|
|
Color |
Black
|
|
