MS2109A Mastech

Description

- The meter is a portable, professional measuring instrument with LCD

 display and back light for easy reading by users. Measuring range switch

 is operated by single hand for easy operation. The meter has overload

 protection and low battery indicator. It is an ideal multifunction meter

 for professionals, factories, schools, fans and family

-

Specification

·         Auto measuring range

·         Full measuring range overload protection

·         The maximum allowable voltage between measurement end and ground:

          600V DC or 600V AC

·         Operational height: maximum 2000 m

·         Display: LCD

·         Displayed maximum value: 5999 digits

·         Polarity indication: automatic indication; '-' means negative polarity.

·         Exceeding measuring range display: '0L' or '-0L'

·         Sampling rate: about 3 times/s, simulation bar 30 times/s.

·         Unit display: has function and power unit display.

·         Auto power off time: 15 min

·         Power supply : 1.5V 3AAA battery

·         Battery under voltage indication: LCD displays '  ' symbol

·         Temperature coefficient: less than 0.1×Accuracy /°C

·         Operating temperature: 18°C to 28°C

·         Storage temperature: -10°C to 50°C

·         Dimension: 220×81×41 mm

·         Weight: approximate 286g(include battery)

·         Safety rating: CE(EMC+LVD) ETL CAT III 600V RoHS

Features:

·         Display: 6000 counts

·         Jaw Opening: Φ26mm/1.0"

·         Auto Power Off

·         Non-Contact Voltage Detector

·         Relative Measurement

·         Diode: 3.3V

·         Continuity Buzzer: <70Ω

·         MAX

·         MIN

·         Data Hold

·         Display Backlight

·         Work Light

·         Low Battery Display

For More Specification Click On Below Link:

http://www.p-mastech.com/product/detail/379
