TOP2009

Description

The TOP2009 programmer is very reliable, specially design for micro-programmed controll unit

and over 2000 type of EPROMs. It has a small size and low power loss.


TOP2009 communicate with PC throught USB port, does not need the external power supply.


USB powered, 70mA~500mA, No AC/DC adapter needed.


Support 2.5V~6.5V device.


Over-current protection on all Pins.


40 pins self-lock sockets.


Working with Winwsows98/SE/ME/2000/XP/Vista/Win7.


Self-detecting the device's manufacturer's name and the type of IC.


COM: USB1.1/2.0


Power: USB 5V or 5V/1A Adapter


Current: Min 70mA/ Max 500mAion


Connect: <2M


Software: TOPWIN 6.0 or newer

Size (mm): 142 x 103 x 23mm
