6022BE HANTEK

Features

* More than 20 kinds of automatic measurement function

* Brightness adjustment, reverse, add, subtract, multiply, and in addition, X-Y

* The waveform data can be time and voltage output to EXCEL, BMP, JPG

* FFT spectrum analysis

* One computer can connect many DSO easily expand the number of channels

* Second Design Labview \ VB \ VC \ Delphi \ C + + Builder development example

Specifications

* Single bandwidth: DC to 20MHz

* Maximum real-time sampling rate: 48MS/s

* Memory depth: 1M

* Vertical resolution: 8Bit

* Impedance: 1MΩ 25pF

* Coupling: DC

* Voltage range: 20mV-5V, 8Steps

* Vertical accuracy: ±3%

* Timebase range: 1ns-5000s, 39 Steps

* Vertical adjustable: yes

* Input protection: Diode Clamp

* X-Y: yes

* Horizontally: Auto, Normal, Single

* Trigger slope: +/-

* Trigger level adjustable: yes

* Trigger source: CH1, CH2, EXT

* Pre-trigger: 0-100%Select

* Sampling rate selection: yes

* Fai line shows: Point / line, brightness adjustment.

* Network: ON / OFF

* Algorithm: Fast Fourier transform, reverse, addition, subtraction, multiplication, and division.

* Cursor display: Frequency, voltage

* Supporting: S/W CD, probes, manual, USB cord

Package Content

1 x OSCILLOSCOPE

1 x S/W and Driver CD

2 x Clip Probes

1 x User Manual On the CD

1 x USB cord
