PIC TRAINER

All port bits are connected to LEDs for displaying pin digital state.
On-board Temperature sensor LM35.
On-board Matrix LCD connecter
On-board I.R receiver for I.R remot applications.
IDC Connector for direct PortC,D pins access.
All port bits LEDs can be connect or disconnect to port pins by DIP switches.
On-board four 7-Segment display
On-board USB 2.0 Programmer for all PIC Families
On-board R.T.C. DS1307
On-board RS232 serial communication module.
On-board 7 Push buttons for single bit input signal
On-board 5Volt supply regulator.
Auto Power get from PC USB port.
IR RECEIVER:
Mostly Infrared light receiver is used in remot control
experiments.IR receiver is connected to C2 bit via a switch if
if disable position disconnect from Bit C2.
