MCD2
Description:
MCD2 MPLAB ICD2 PIC Debugger/Programmer+Programming Module Description New design
Enhanced USB ICD2 PIC debugger and programmer for Microchip's PIC and dsPIC digital
signal controllers. Using the powerful user interface of the MPLAB IDE (Intergrated Development
Environment). USB ICD2 In-circuit Debugger and Programmer: -USB (Full Speed 2 M bits/s) /
RS-232 interface to host PC -Real time background debugging -MPLAB IDE GUI
(free copy included) -Built in over-voltage/short circuit monitor -Firmware upgradeable from PC
-Totally enclosed -Supports low voltage to 2.0 volts. (2.0 to 6.0 range) -Diagnostic LEDs
(Power, Busy, Error) -Reading/Writing memory space and EEDATA areas of target microcontroller
-Programs configuration bits -Erase of program memory space with verification -Periphera
l freeze-on-halt stops timers at breakpoints -Built-in USB Reset self-reconnected function. -High
reliably ICs and Components. -Compact design with mounting hole. -Increased overcurrent
protection -Increased electrostatic protection -Increased User Board first opened power protection
-Increased Users Board Overvoltage Protection The MPLAB ICD 2 connects using USB or
RS-232 between the design engineer's PC operating with MPLAB IDE and their product board
(target) being developed. It acts as an intelligent interface/translator between the two, allowing
the engineer to look into the active target board's microcontroller, viewing variables and registers
at breakpoints with MPLAB watch windows. A breakpoint can be set to halt the program at a
specific location. The program can be single-stepped or run at full speed. At breakpoints, data
and program memory can be read and modified. Additionally, the MPLAB ICD 2 can be used
to program or reprogram the Flash-based microcontroller while installed on the board.
Package list 1X MCD2(MPLAB ICD2) Debugger / Programmer 1X USB cable 1X Uerial cable
1X Universal Programming Module 1X 6-Pin Individual ICSP Cable 1X RJ12 Connection Cable
1X Power supply 1X CD-ROM
