L298 Motor Driver Controller Board

The L298N driver module, using ST L298N chip can directly

Drive two 3-30V DC motor, and provides a 5V output interface

, you can chip circuitry to 5V power supply, support 3.3VMCU

control, you can easily control the DC motor speed and direction,

You can also control the 2-phase stepper motor, smart car essential.

Product parameters:

1 Driver chip: L298N dual H-bridge driver chip


2 Terminal driver part of the supply area VMS: +5 V ~ +35 V


3 Drive part of the peak current Io: 2A / Bridge


4 Logical part of the terminal power supply range Vss :4.5-5 .5 V


5 Logical part of the operating current range: 0 ~ 36mA


6 The control signal input voltage range: 4.5-5.5V low 0V high


7 Maximum power consumption: 20W


8 Storage temperature: -25 ~ +130


9 Driver Board Size: 55mm * 60mm * 30mm


10 Driver board Weight: 33g


11 Other features: control direction indicator, power indicator,

current detection, logical part of the plate to take power interface.
