TM-8812

Description:

TM-8812 portable thickness gauge. Range: 1.2 to 225mm Resolution: 0.01mm Display:

Selectable metric or imperial units. 4 Digit LCD 10mm high. Velocity: 1000 - 9000 m/s,

sensor operating temperature 0-50°C, Battery: Operated 4 x AAA cells provides 20 hours

continuous operation. Built in calibration test block. Suitable for thickness measurment on

all metals including steel, cast iron, aluminium, copper, brass, titanium sheet metal, also glass,

ceramics and hard plastics. Supplied with carry case . Accuracy ±0.5%.

Computer Interface

Windows software and USB cable for TM-8812 handheld thickness meter. Enables data to be

transferred in real time to your PC with a table view and max/min readings. Data can be saved

and exported to XLS and also viewed in chart format.

Specification

Model: TM-8812
Measuring range: 1.2-225mm, 0.05-9inch
Operating principle: ULTROSONIC
Materials measured: Any hard materials, including steel, cast iron, aluminum, red copper, brass,
zinc, quartz glass, polyethylene, PVC, gray cast iron, nodular cast iron and other materials
Sound velocity: 500-9000m/s
Lower limit steel pipes: Diameter15x2.0mm, diameter20x3.0mm determined by the transducer
Calibration block: Included
Resolution: 0.1mm
Accuracy: +/-(0.5%n+0.1)
RS232C interface: With RS232C
Power supply: 4x1.5V AAA (UM-4)battery
Battery indicator: Low battery indicator
Operating conditions: 0-+45C(32F-104F), ≤90%RH
Dimensions: 120x62x30mm
